PART OF THE DAY - with Summon Electronics!
The LMD18201 is a 3A H-Bridge designed for motion. We are talking about dc and stepper motor drives, servo, factory automation robots even printer and plotters. This particular device is a lead free part and will be used in a vacuum sealer.
Key Facts of LMD18201 we discovered:
| MSL | : | 1 |
| Dimensions are | : | 20.02 x 4.5 x 10.69 mm |
| Packaging | : | These came in non factory box |
| Part Marking Format | : | Lot code part number |
| Datecode | : | 2010 |
| Description of part | : | LMD18201 3A, 55V H-Bridge NDJ0011B |
Observation
Part number:
LMD18201
Manufacturer:
NATIONAL
Package/ Case:
TO-220
Top View
Side View
Measurements
Micrcoscope View
PART DESCRIPTION
LMD18201 3A, 55V H-Bridge NDJ0011B
DATA SHEET:
NO DATA
